Gallagher MBS200 20W Solar Kit

The MBS200 20W solar kit helps you maintain reliable livestock control in remote paddocks without running mains electricity to the fence. It combines the flexible Gallagher MBS200 energiser with a compact 20W solar panel, regulator and durable mounting hardware.

With 2 joules of stored energy and 1.5 joules of output energy, the MBS200 provides dependable power for cattle, sheep, horses, goats and other livestock when matched to a correctly designed fence and earth system.

Why Choose the MBS200 20W Solar Kit?

• Practical off-grid power for remote paddocks
• 2 joules of stored energy
• 1.5 joules of output energy
• Recommended for up to 5km of working multiwire fence
• Up to 20km under ideal fence conditions
• Suitable for properties up to approximately 8 hectares
• Compact 20W solar panel with regulator
• Mains, external battery and solar-compatible energiser
• LED bar graph displays fence-voltage performance
• LED battery indicator assists with battery monitoring
• Smart battery management helps prevent excessive discharge
• Water-resistant portable enclosure
• Built-in lightning protection

Compact Solar Power for Suitable Locations

The included 20W panel provides a compact solar-charging solution for suitable Australian locations with adequate sunlight. It may be particularly useful where a smaller panel is preferred and the fence is kept in good working condition.

Solar-panel requirements vary according to location, season, battery capacity, fence load and available sunlight. The larger 40W MBS200 kit may be a better option in lower-sunlight regions or where additional charging capacity is required.

Flexible Power Wherever You Need It

The Gallagher MBS200 can operate from mains electricity, an external 12V battery or a compatible solar system. This flexibility allows the energiser to be used for permanent installations, temporary paddocks or remote fences where mains power is unavailable.

Mains, battery and fence lead sets are supplied with the energiser, allowing the unit to adapt if your power requirements or paddock layout change.

What Is Included?

• Gallagher MBS200 multi-powered fence energiser
• Mains, battery and fence lead sets
• Fully tested 20W solar panel
• Solar regulator to control power flow and protect the battery
• Stainless-steel mounting brackets
• Mounting bolts and clamps
• Multiple panel-tilt positions for improved sunlight exposure

Please note: A suitable external 12V battery is required and is not included.

Understanding the 20km Rating

The advertised 20km distance represents a clean, well-constructed fence operating under ideal conditions. Gallagher’s recommendation of up to 5km of multiwire fencing is generally a more practical guide for working farm conditions.

Vegetation touching the live wires, inadequate earthing, damaged insulators, poor joins, unsuitable conductors and long lead-out distances can all increase the electrical load and reduce effective fence performance.

Solar Panel Positioning and Battery Care

Install the solar panel where it receives strong, uninterrupted sunlight throughout the day. Avoid shade from trees, buildings and machinery, particularly during the morning and afternoon.

The supplied regulator controls the power flowing to the battery. The MBS200’s smart battery-management system also helps prevent damaging over-discharge when solar input is insufficient. Regular battery inspection and maintenance are still important.

Correct Earthing Is Essential

An effective earth system allows the electrical pulse to travel through the animal and return to the energiser. Without adequate earthing, even a correctly operating MBS200 may produce a weak shock along the fence.

Install suitable galvanised earth stakes in permanently moist ground. Dry, sandy or rocky soil may require additional stakes or an earth-return fence design. Keep the electric-fence earth system separated from building earths and underground services.

Product Specifications

• Brand: Gallagher
• Model: MBS200
• Combined product SKU: G38911 G49521
• Stored energy: 2 joules
• Output energy: 1.5 joules
• Recommended multiwire distance: Up to 5km
• Ideal-condition multiwire distance: Up to 20km
• Recommended property size: Up to approximately 8 hectares
• Solar-panel output: 20 watts
• Average energiser power consumption: 2.6 watts
• Power sources: Mains, external 12V battery or solar
• Energiser height: 117mm
• Energiser width: 224mm
• Energiser depth: 224mm
• Energiser weight: Approximately 2kg
• Outdoor suitable: Yes, when installed according to instructions
• Warranty: Three-year Gallagher manufacturer warranty
• External 12V battery: Required and sold separately

A Practical Solution for Remote Fencing

The Gallagher MBS200 20W solar kit gives you a compact, flexible way to operate an electric fence away from mains electricity. Correct panel positioning, battery selection, earthing and fence maintenance will help you achieve dependable performance.

Contact Horsley Wholesale if you need help choosing between the 20W and 40W MBS200 kits or selecting a suitable battery and earth system.
